2017 6061 Aluminum alloy pipe for electronics

Aluminum alloy pipe for electronics, communications engineering is widely used, Chalco aluminum use the indirect extrusion in production of high quality alloy seamless tube, which can be used in electronic imaging equipment, such as photosensitive drum, heating roller and the other components.



Production technology: Indirect extrusion technology, cold drawn technology, the elimination of internal stress
Advantages:
Uniform color anodizing;
100% no welding line;
The performance is higher than the national standard.





Flanges alloy: 2017 T4
Product features: moderate hardness, good turning performance, can be used in CNC antomatic lathe.
Drum alloy: 6061 T6
Features: good anodizing quality, uniform composition, high dimensional accuracy.

Specification:
Alloy: 2017 6061
Temper: T6、T4
OD: 3--130mm
ID: 3--100mm
Length: 1000mm--6000mm

Chemical Composition of 2017  6061 Aluminum Tube Pipe
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga V Ti Other Min.Al
2017 0.20-0.8 0.7 3.5-4.5 0.40-1.0 0.40-1.0 0.10 - 0.25 - - - 0.15 Remainder
6061 0.40-0.80 0.7 0.15-0.40 0.15 0.8-1.2 0.04-0.35 - 0.25 - - 0.1 0.15 Remainder

Physical Property of 2014 2017 6061 Aluminum Tube Pipe
Alloy Temper Wall thickness
/mm
Room temperature Test Result
Tension Strength/MPa Yield Strength/MPa Elongation/%
A50mm A
Not less than
12.50~18.00 440 400 - 6
>18.00 470 400 - 6
2017 O all ≤245 ≤125 16 16
T4 all 345 215 12 12
T1 all 335 195 12 -
6061 O all 170 105 16 14
T1 ≤16.00 260 240 8 -
T42 all 180 85 16 14
T62 ≤6.30 260 240 8 -
>6.30 260 240 10 9
T4、T4510、T4511 all 180 110 16 14
T51 ≤16.00 240 205 8 7
T6、T6510、T6511 ≤6.30 260 240 8 -
>6.30 260 240 10 9
F all - - -- -
