Chemical Composition | |||||||||||||
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ga | V | Ti | Other | Min.Al |
6162 | 0.4-0.8 | 0.5 | 0.2 | 0.1 | 0.7-1.1 | - | - | 0.25 | - | - | 0.1 | 0.15 | Remainder |
6262 | 0.4-0.8 | 0.7 | 0.15-0.40 | 0.15 | 0.8-1.2 | 0.04-1.4 | - | 0.25 | - | - | 0.15 | 0.15 | Remainder |
6064 | 0.4-0.8 | 0.70 | 0.15-0.40 | 0.15 | 0.80-1.2 | 0.25 | - | 0.25 | - | - | 0.15 | 0.15 | Remainder |
6063 | 0.2-0.6 | 0.35 | 0.10 | 0.10 | 0.45-0.9 | 0.10 | - | 0.25 | - | - | 0.10 | 0.15 | Remainder |
6066 | 0.9-1.8 | 0.50 | 0.7-1.2 | 0.6-1.1 | 0.8-1.4 | 0.4 | - | 0.25 | - | - | 0.2 | 0.15 | Remainder |
6A02 | 0.5-1.2 | 0.5 | 0.2-0.6 | 0.15 | 0.45-0.9 | - | - | 0.20 | - | - | 0.15 | 0.15 | Remainder |
Physical Property | ||||||
Alloy | Temper |
Wall thickness /mm |
Room temperature Test Result | |||
Tension Strength/MPa | Yield Strength/MPa | Elongation/% | ||||
A50mm | A | |||||
Not less than | ||||||
6162 | T5、T5510、T5511 | ≤25.00 | 255 | 235 | 7 | 6 |
T6、T6510、T6511 | ≤6.30 | 260 | 240 | 8 | - | |
>6.3-12.50 | 260 | 240 | 10 | 9 | ||
6262 | T6、T6511 | all | 260 | 240 | 10 | 9 |
6063 | O | all | ≤130 | - | 18 | 16 |
T1 | ≤12.50 | 115 | 60 | 12 | 10 | |
>12.50~25.00 | 110 | 55 | - | 10 | ||
T42 | ≤12.50 | 130 | 70 | 14 | 12 | |
>12.50~25.00 | 125 | 60 | - | 12 | ||
T4 | ≤12.50 | 130 | 70 | 14 | 12 | |
>12.50~25.00 | 125 | 60 | - | 12 | ||
T5 | ≤25.00 | 175 | 130 | 6 | 8 | |
T52 | ≤25.00 | 150-205 | 110-170 | 8 | 7 | |
T6 | all | 205 | 170 | 10 | 9 | |
T66 | ≤25.00 | 245 | 200 | 8 | 10 | |
F | all | - | - | - | - | |
6064 | T6、T6511 | 10.0-50.0 | 260 | 240 | 10 | 9 |
6066 | O | all | ≤200 | ≤125 | 16 | 14 |
T4、T4510、T4511 | all | 275 | 170 | 14 | 12 | |
T42 | all | 275 | 165 | 14 | 12 | |
T62 | all | 345 | 290 | 8 | 7 | |
T6、T6510、T6511 | all | 345 | 310 | 8 | 7 | |
6A02 | O | all | ≤145 | - | - | 17 |
T4 | all | 205 | - | - | 14 | |
T62 | all | 295 | - | - | 8 | |
T6 | all | 295 | - | - | 8 |
